SECFETRONIK
16mm LED illuminated Pushbutton
LED illuminated Round pushbutton with 16mm cutout mounting. Button shape in round, square or rectangular.
Part Number:
9OP1-LAS1^-*/**/***/P (i.e:9OP1-LAS1-AR/11/R/024/P for an 24V illum. round 1no1nc mômentary red button) Black 9OP1-LAS1-XX-*/**/***/P (i.e:9OP1-LAS1-AR/11/R/024/P for an 24V illum. round 1no1nc mômentary red button) Black
Front Bezel Colour:
Black
^Button shape:
Round "AR" / Square "AF" / Rectangular "AJ"
* Contact (Momentary):
"11" - 1no1nc (1CO) or "22" - 2no2nc (2CO)
* Contact (Maintain):
"11Z" - 1no1nc (1CO) or "22Z" - 2no2nc (2CO)
** Button & illumination Colour:
"W" - white / "G" - green / "R" - red / "Y" - Yellow / "B" - Blue
*** Operating voltage:
VAC/DC - 012, 024, 110 & 220
Operating Temperature:
-25°C ~ +55°C
LED type / voltage:
S14, dual polarity, 12/24/110/220 VAC/DC
Terminal pin type:
Pin terminal (2.8 x 0.5mm)
"Material: "
Head: PC Body: PC Base: PA
