16mm / 22mm Ø Buzzer
16mm / 22mm Ø Buzzer. 22mm come in different signalling mode - Illumination & audible (both steady or flicker).
Front Bezel Colour:
Black (16mm), Red or Black (22mm)
Front Bezel Shape:
Round (16mm and 22mm) / Square (16mm) / Rect (16mm)
Panel cutout:
16mm Ø or 22mm Ø
Operating voltage:
16mm Ø - 24V AD/DC / 22mm Ø - 24 or 22o V AC/DC
LED type (22mm Ø only):
Built-in (22mm Ø only)
Buzzer intensity:
16mm Ø - 75 decibel / 22mm Ø - 80 decibels
See MoreClose
Download PDF
Enquire Now
Mounting holes Front Bezel Voltage Singalling P/N
16mm Ø Round Black 24 VAC/DC Buzzer 9OP1-LAS1-AY-B/024
16mm Ø Square Black 24 VAC/DC Buzzer 9OP1-LAS1-AF-B/024
16mm Ø Rectangular Black 24 VAC/DC Buzzer 9OP1-LAS1-AJ-B/024
22mm Ø Round Blac 220 VAC/DC Buzzer 9OP5-AD16-22M/220V
22mm Ø Round Blac 24 VAC/DC Buzzer 9OP5-AD16-22M/24V
22mm Ø Round Red 220 VAC/DC Buzzer and Light (Steady) 9OP5-AD16-22M/R/220V
22mm Ø Round Red 24 VAC/DC Buzzer and Light (Steady) 9OP5-AD16-22M/R/24V
22mm Ø Round Red 220 VAC/DC Buzzer and Light (Flicker) 9OP5-AD16-22SM/R/220V
22mm Ø Round Red 24 VAC/DC Buzzer and Light (Flicker) 9OP5-AD16-22SM/R/24V
