TENSE
ON & OFF Delay Digital Timer (with Trigger) - DRV-10
DRV-10 triggered digital timer with ON and OFF delay is designed to be used where ever
time dependent control is required.
Operating Voltage (A1-A2):
230V AC 50/60Hz
Operating Voltage (A2-A3):
24V AC/DC
Trigger Voltage (TR):
24V - 240V
Operating Temperature: -
20°C. +55°C
Working Time Range (t):
0,1sec. - 99 min.
Display:
1x2 LED Display, 2x LEDs.
Connection Type:
Assembled on the din rail.
Contact:
5A 250V AC Resistive Load
