TENSE
Multifunctional Timer Relay - ERX-10
ERX-10 timer relay is specifically designed for controlling the time and incoming data and can be used in industry, residential, factory facilities.
Operating Voltage(Un).
12V ~ 240V AC/DC
Operating Frequency.
50/60 Hz.(AC)
Operating Temperature.:
-20°C ~ +55°C
Time(t):
0.1sec. ~ 30hours
Display:
Relay, T switch(S), status(M) and power(On) leds
Connection Type:
Terminal connection
Contact:
5A/250V AC (resistive load)
Mounting:
Assembled on the din rail.
Cable Diameter:
0.22mm² - 1.5mm²
